Can you have a junction box in the ceiling?

Can junction boxes be covered with drywall?

Junction box covers must remain accessible; they cannot be covered with drywall or other surface material. A junction box is most often used where an electrical circuit branches off in two or more directions from a location where an outlet or fixture is not practical.

Access the area above the ceiling in a home. Follow the path of flexible conduits across the ceiling insulation to a point where two or more conduits appear to intersect. Pull back the insulation at these points to expose junction boxes.

Do junction boxes need to be secured?

Securing Cables

Article 334.30 states that cables coming out of the junction boxes should be secured within 12 inches of the box in all boxes equipped with cable clamps. These cable clamps are not to be removed. 314.17(C) states that cables must be secured to the receptacle box.
Nov 17, 2019

Do you need a junction box for ceiling light?

If you're wondering how you install a light fixture without an electrical box, the short answer is that you don't. ... You can't install a light fixture without a junction box, but the fact that there's no box at the spot where you want to install the light doesn't mean you can't install the light.Oct 21, 2019

image-Can you have a junction box in the ceiling?
image-Can you have a junction box in the ceiling?

When would you use a junction box?

You'll need a junction box if you can't make the connections inside an existing electrical box. You should install the box with the opening facing out from the wall so all the wires inside are accessible. Like any electrical box, it should be installed so that the edge of the opening is flush with the wall.


How do I know if my junction box will hold a ceiling fan?

The manufacturer must have marked the outlet box system to indicate that it is acceptable for ceiling fan installations. If the original box is not listed for this purpose, it must be retrofitted and attached securely to the building structure.


Is it OK to use a junction box to extend wiring?

Yes. You can definitely use a junction box to extend your wiring. To do this, start by turning off the power. Then inspect the place and cut the required openings.Mar 16, 2021


Are junction boxes bad?

Junction boxes are designed to protect your wiring connections from damage. Making electrical connections outside of a junction box will damage the wiring and increase the risk of heat and sparks.


Can you mud over junction box?

Applying drywall over a junction box is never a good idea. According to the code, your junction boxes should always remain accessible, regardless of how good of a splice you made. ... So, the best option you have is to not cover junction boxes.Apr 2, 2021


Are there plastic junction boxes?

Plastic electrical boxes, sometimes called junction boxes, have plenty of pluses, including low cost, convenience, and ease of installation. ... Both plastic and metal boxes come in a full range of types and sizes for both indoor and outdoor applications.Jun 8, 2021


Why are hidden junction boxes bad?

A safety-related problem with hidden junction boxes is that they can make it impossible to evaluate and correct dangerous conditions that might arise in future. If e.g. a home gets hit by a high-voltage surge, it may be necessary to inspect all of the junction boxes for signs of damage.Nov 10, 2020


Is a junction box the same as a breaker box?

In case of a short, a breaker will trip and cut off electricity to its circuit. To reset the circuit only requires resetting the breaker. (We recommend you label each breaker for the part of the house it controls. Use paper labels and put them beside the switches.Sep 2, 2019


How do I find a buried electrical box?

Most outlets are located 18 to 24 inches off the floor, and wall switches are generally located about 4 feet above the floor. Carefully scan the wall surface in these areas for a hump created by the hidden box pushing against the drywall.


Is there any acceptable way to cover a junction box?

  • As long as there are no wires inside the box, you can cover it with drywall. If the box is still acting as a junction box, however, and wires are joined inside it, the electrical code mandates a removable cover. Covers come in plastic or metal, and you attach them with machine screws.


Can I move junction box?

  • Any junction box can be moved and re-located. Just depends upon the ease or difficulty in re-locating a box. The more cables or wires in a junction box = additional labor required to re-locate the box.


What is the best way to cover an electrical box?

  • If you have an electrical box in your attic, cover it with a plastic or metal blank cover that is an appropriate size for your electrical box. Turn off the breaker in your home’s breaker box to turn off the electricity to the wiring.


What is a junction box?

  • A junction box – also known as an ‘electrical box’, ‘jbox’, ‘or ‘terminal box’ – is a protective box where wires are interconnected. Junction boxes are found both indoors and outdoors.
